GNI
Power Relay

. Max high inrush:120A 20ms

. Low height: 15.7 mm

. 5kV dielectric strength (between coil and contacts)

. Creepage distance: 10mm

. Plastic sealed and flux proofed types available

. UL insulation system: Class F

. Environmental friendly product (RoHS compliant)

. Dimensions: 29.0 x 12.7 x 15.7 mm

Household Electrical Appliance /

Automation System

Electrical Equipment /

Instrument /

Meter

Telecommunication Facilities /

Remote Control Facilities

. Contact Arrangement: 1 Form A, 1 Form C

. Coil Voltage: 5VDC~110VDC

. Contact Material: AgAlloy

. Contact Rating: 16A 250VAC

. Coil Power: Approx. 0.4W

. Inrush Rating (120VAC):

   NO: TV-5 80A

   120A / 20ms

. Max. Switching Power: 4000VA

. Max. Switching Voltage: 440VAC

. Max. Switching Current: 16A

. Terminal Type: PCB

. Weight: Approx. 13.5g

Dimensions: 29.0 x 12.7 x 15.7 mm

UL / VDE / CQC
