AF

Automotive Relay

Features: 20A Switching capability; 1 Form A contact arrangement; 2.8mm QC terminals available; Ambient temperature range: -40℃ to 125℃; Environmental friendly product (RoHS compliant)

Application

Central Door Lock System
Headlight Control
Fuel Pump Control
Horn Control
A/C Compressor Clutch
Car Alarm System
Wiper Control
Speed-limit Indicator Control, etc

Add Inquiry (0) AF Relay Spec

Model: AF

Product Detail	Coil Voltage Form: DC relay Coil Voltage: 12/24VDC Contact Material: Ag Alloy Contact Arrangement: 1A Contact Rating: 20A 14VDC / 10A 28VDC Coil Power Consumption: Without resistor: Approx. 0.96W With R1 Resistor: Approx. 1.1W Max. Switching Power: 280W Max. Switching Voltage: 30VDC Max. Switching Current: 20A Weight: Approx. 13g
Dimensions (mm)	16.0 × 15.0 × 23.7
