GH

General Power Relay

Features: 15A switching capability; 1 Form A, 1 Form B and 1 Form C configurations; Standard PCB layout; Plastic sealed and flux proofed types available; UL insulation system: Class F available; Environmental friendly product (RoHS compliant)

Application

Smart Home Solution
Street Light Control
Home Appliance
Temperature Control
Industrial Control
Medicial Equipment
Security System
Anti-Theft System, etc.

Add Inquiry (0) GH Relay Spec

Model: GH

Product Detail	Coil Voltage Form: DC relay Coil Voltage: 5~48VDC Contact Arrangement: 1A, 1B, 1C Contact Material: Ag Alloy Contact Rating: NO: 15A 250VAC / 277VAC NC: 10A 250VAC TV-5 120VAC / 240VAC Coil Power Consumption: 0.36W / 0.45W Max. Switching Power: 4155VA Max. Switching Voltage: 277VAC Max. Switching Current: 15A Weight: Approx. 12g
Dimensions (mm)	20.3 × 16.5 × 20.5
