GC

Subminiature Intermediate Power Relay

Features: 10A switching capability; 1 Form A and 1 Form C configurations; Subminiature, standard PCB layout; Plastic sealed and flux proofed types available; UL insulation system: Class F; Environmental friendly product (RoHS compliant)

Application

Smart home solution
Home Appliance
Temperature Control
Industrial Control
Medicial Equipment
Security System
Anti-Theft System
Household appliance ...etc

Add Inquiry (0) GC Relay Spec

Model: GC

Product Detail	Coil Voltage Form: DC relay Coil Voltage: 3~48VDC Contact Arrangement: 1 Form A, 1 Form C Terminal Type: PCB Contact Current: 5A & 10A available Coil Power: Sensitive 0.2W & Standard 0.45W available Max. Switching Power: 2500VA / 300W Max. Switching Voltage: 250VAC / 30VDC Max. Switching Current: 10A Weight: Approx. 6g
Dimensions (mm)	18.4 × 10.2 × 15.3
Qualification	UL / VDE / CQC
